Sharpless	Instrument	Exposure	Camera	Filters
SH2-9	MakNewt 8 inch F/4	14 Hours 30 Minutes	QSI 583 WSG	H-Alpha, RGB

Size:

Color Black and White

Zoom:

Pan:

Rotate

Sharpless	Instrument	Exposure	Camera	Filters
SH2-9	MakNewt 8 inch F/4	14 Hours 30 Minutes	QSI 583 WSG	Clear, H-Alpha, RGB

Size:
Full Size

Sharpless	Instrument	Exposure	Camera	Filters
SH2-9	MakNewt 8 inch F/4	7 Hours	QSI 583 WSG	H-ALpha

Sharpless	SH2-9
Common Name	Sharpless 9
Constellation	Scorpius
RA	16h 21m
DEC	-25d 35m
Size	80
Shape	Irregular
Brightness	Midrange
Object Type	Diffuse Nebula
Type	Emission
Other Catalog #	Gum 65

This is one you would most definitely want to add to your list of images because it lies next to the famous globular star cluster known as Messier 4. If your field of view is at least 100 by 70 arc minutes in size, you can frame the two in the same image. To add to this, SH2-9 has an excellent reflection nebula around the star itself which is surrounded by the nice red emission part of this nebula. The nebula responds very well to a Hydrogen Alpha filter, but you will need a long exposure to capture the nebula that extends around the main star. You need to be careful of getting strong reflection from Antares which is not far, so you may want to include Antares into the image if you can. The H-Alpha channel will hide the reflection nebula seen in this image, so you will need to be careful when processing it. This version of SH2-9 was published in the November 2007 issue of Sky and Telescope and in Beautiful Universe 2008, also printed by Sky and Telescope.
